Tower UPS AC208V/AC220V/AC240V

Home > Products > UPS > Tower UPS AC208V/AC220V/AC240V

BVT 192VDC to 208/220/230/240VAC 10000VA UPS Battery Backup with Pure Sine Wave Output External Battery




Inquiry
  • Feature
  • Parameter
  • get in touch
  • downloads

Zero Transfer time:True Double Conversion Online UPS, Provide most comprehensive protect mission critical equipment from wide range power quality issues.

DSP Digital Control Based:Advance DSP base digital control bring high performance of high input Power factor, low distortion , supply the load with perfect sine wave AC power supply

Three Level Inverter:Low harmony noise, high efficiency , well adapt to wide range of loading equipment, include high power laser printer, ultrasonic cleaner etc.

Ultra Wide Input Mains range:Strong compatible with ultra with electric environment, stay well with ultra wide range mains of 50V~145V, 40~70Hz ,dramatically reduce battery discharge , prolong battery life

Best Loading Capability:Up to 0.9 Output Power Factor , 50/60 Hz Automatically adapting, selectable voltage , perfectly match all kind of application

Genset Compatible:Capable of work with wide range of Genset, isolate fluctuation and noise from Genset , provide stable and clean power supply to the user equipment.

High Input power factor:Thanks to digital controlled PFC Technology, 0.99 input power factor, effectively avoid power pollution , save energy expense for customer

Reliable design:Made with strong Glass fiber base (FR4) double side PCB, company with large span component, greatly improve reliability in harsh environment, Well designed ventilation and conformal coating , avoid dust accumulation ,improve resistant to corrosion.

Open to customization:Based on powerful controller and open architecture, the product is able to be customized to match need of integration of automatic system or intelligent supervisory system


Model10KS
CapacityVA/W10kVA/9000W
TopologyDouble Conversion Online UPS
PhaseSingle Phase Input Single Phase Output
Mains InputWiringL/N+PE
Rated Voltage208/220/230/240VAC
Voltage Range110~285VAC
Frequency Range40Hz~70Hz
Input Power Factor≥0.99
AC OutputWiringL/N+PE
Output Voltage208/220/230/240VAC
Voltage Regulation±1%
Output Frequency50/60±4Hz(Sync Mode) / 50/60Hz±0.1%(Free Run)
WaveformPure Sine Wave
Distortion<2%(Linear Load)
(THDV%)<7%(None-Linear Load)
Over load1Min@105%~125%Rated Load
capability30Sec.@125%~150%Rated Load

0.5Sec.@>150%Rated Load
EfficiencyLine mode93%
Battery Mode91%
BatteryRated Battery Voltage ①192VDC
&Internal
ChargeBattery Capacity

192/240VDC External


Backup Time

External Battery Depends


Charging CurrentStandard Model with Internal Battery:1A

Long Backup Time Model :4A

Optional Configuration to Order1. External Battery Module Connector for Standards Model

2. Battery Capacity 7AH/9AH

3. Battery Quantity(2/4/6pcs) or (3/6/6pcs)
PhysicalChassis StyleTower
Tower DimensionC6KS：190(W)X318(H)x366(D)mm,  C10kS: 190(W)X340(H)x534(D)mm
C6K-12BAT:190(W)X360(H)x534(D)mm
 C6K-16BAT, C10K: 190(W)X456(H)x534(D)

Weight (kg)9.1
HMILCD DISPLAYInput Mains Voltage, Frequency, Load level, Operation Mode, Health Status
Standards1.RS232 PORT  2.EPO / ROO Port  3.Intelligent Slot  4.USB Card (not HID)
Communication Interface
Optional Extension Card5. NetWork Card:  Support SNMP/TCP/IP for remote monitoring the UPS via Smart Phone APP, Web page,  PC Monitor Software , Support Server / NAS shutdown
6. RS485-MODBUS Card,  LAN(TCP IP)-MODBUS Card,
7. Mini AS400 Relay Card
Operating EnvironmentTemperature range-10~50oC
EnduranceRelative Humidity0-98%（Non-condensing）

Acoustics Noise<55dB @ 1 meters
